Synthesis Soprano A Class Integrated Tube Amplifier

Synthesis

Synthesis Soprano A Class Integrated Tube Amplifier

Price
£1,449.00
Product Condition
New
12W A Class Integrated Stereo Amplifier
Product Colour
- Optional

Following the success of the much-celebrated NIMIS, Synthesis took on the challenge of recreating a 12W A Class integrated stereo tube amplifier.
Using a new technologies a new business development and Luigi Lorenzon's constant pursuit of perfection, he succeded in creating an entry level amplifier that is able to satisfy even the most dedicated audiophile.
New model of stereo tube amplifiers with DAC's on board, guaranteeing exceptional sonic performance from any digital source.
Made with the finest materials and advanced technology, the SOPRANO is a sophisticated blend of research and experience.
Designed without compromise it provides a rich sound and faithful music reproduction.
The SOPRANO provides a minimum of 12 Watts per channel, power output from a pair of EL84's in Ultra-Linear (UL) - push/pull operation.
The SOPRANO features a newly designed custom output transformer resulting in a rich sound stage but with an authority that belies its 12Wpc.

Synthesis Soprano A Class Integrated Tube Amplifier

  • USB DAC on board 24bit for a extraordinary listening experience from computer’s file.
  • Hi quality Phono stage for MM cartridges.
  • SPDIF inputs (Coax and Optical) built around a AKM chip. 24 Bit 192KHz Hi Quality DAC for an extraordinary sound result.
  • The Output transformer uses a Hi-Grade iron-Silicon for superb frequency reproduction & width. With this newly designed custom output transformer unique to the Soprano it's possible to achieving a highly delicate & precise sound reproduction faithful to the original recording.
  • The power supply & output transformers are held by an extremely rigid structure that keeps the unit free from unwanted vibrations which further helps reduce unwanted noise to the tubes.
  • Gold plated professional binding posts for a continued oxidisation free connection further improve sound refinement.
  • Sockets Ceramic sockets for a continued oxidisation free connection further improve sound refinement.
  • Components for the amplifier have been selected with great care throughout. Only the best available components are considered & all must undergo an exhaustive analysis of their sonic influence prior to final selection.
  • All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process & at the end of this, selects the perfect tubes which are then matched for a perfect balance.
Specifications
  • Power stage (1 ch.): Matched pair EL84/6BQ5
  • Input stage (1 ch.): Hi Performance audio OP-AMP JRC4580
  • Driver (1 ch.): Matched pair MJD340 (Designed for audio amplifier)
  • Input impedance: 100Kohm
  • Input sensitivity: 100mV RMS for rated power
  • Output tap: 6 Ohm
  • Power stage config.: Push-Pull Ultra Linear 43% tap
  • Power output: 12W RMS into 6 ohm A Class
  • Power Bandwidth: 15Hz to 50KHz - 3,0dB
  • Frequency response: 20Hz to 20KHz - 0,5dB
  • Distortion: 1% @ 1KHz max power (12W)
  • Signal/Noise ratio: >90dB A weighted
  • Analogue Inputs: 1 Line, 1 Phono MM (47Kohm) 40dB gain
  • Digital Inputs: 1 SPDIF coax, 1 SPDIF optical 1 USB “B” type Windows/Mac/iOs/Android compatible
  • Max Resolution: 24 Bit 192KHz
  • Remote control: Volume and Sources control
  • Power requirements: 230VAC 50Hz -120VAC 60Hz - 80W maximum
  • Dimensions: (w,d,h): 310 x 295 x 150mm (12,2” x 11,6” x 5,9”)
  • Weight: 10,0 Kg (22.0 lbs)
